An elegant, slim loudspeaker with a well balanced acoustic, real sub-bass reproduction and attractive price is a contradiction?! The LINEA-HEIDELBERG surprises and questions the standard: With valuable front decors in high-glossy black and decent designed enclosures in three different styles.

    • HD-PF200BA

      Black Ash

    • HD-PF200CH

      Cherry

    • HD-PF200RW

      Rosewood



    HEIDELBERG, HD-PF200

    Floorstand Loudspeaker



    Clear and balanced sound reproduction, thanks to a homogeneous sound tuning. Remarkable sub-bass performance and still a very slim front panel thanks to a sideways mounted 8”/20cm bass driver. Suitable for 2ch stereo and surround sound applications.



    Drive Units





    Power Handling

    Frequency Response

    Nominal Impedance

    Crossover Frequency

    Crossover Slope

    Dimensions (W/H/D)



    Download



    1 x 0.8" (20mm) Tweeter
    2 x 4" (10cm) Mid-Bass
    1 x 8" (20cm) Woofer

    150 W RMS / 200 W max.

    20 - 20.000 Hz

    6 Ω

    140 Hz / 2.200 Hz

    6 / 12 / 12 dB / Octave

    15,6 / 102 / 32 cm

    6.1 / 40.2 / 12.6 inch

    Manual

    • HD-PR20BA

      Black Ash

    • HD-PR20CH

      Cherry

    • HD-PR20RW

      Rosewood



    HEIDELBERG, HD-PR 20

    Bookshelf / Rear Loudspeaker



    Ideal extension for HD-PF200 floorstand speakers to form a surround sound system. Further, the HD-PR20 speakers can also be used as small bookshelf speakers in stereo applications. A classical, decent design fits them in almost all living scenarios.



    Drive Units



    Power Handling

    Frequency Response

    Nominal Impedance

    Crossover Frequency

    Crossover Slope

    Dimensions (W/H/D)



    Download



    1 x 0.8" (20mm) Tweeter
    1 x 4" (10cm) Mid-Bass

    80 W RMS / 100 W max.

    50 - 20.000 Hz

    6 Ω

    3.000 Hz

    12 / 6 dB / Octave

    14 / 23 / 18 cm

    5.5 / 9 / 7 inch

    Manual

    • HD-PC20BA

      Black Ash

    • HD-PC20CH

      Cherry

    • HD-PC20RW

      Rosewood



    HEIDELBERG, HD-PC 20

    Center Loudspeaker



    Due to a very neutral sound tuning which is neither intrusive, nor lacking in details, the HD-PC20 center speaker is the ideal addition for surround sound systems. The compact size and decent design make it easy to integrate the center in your living scenario.



    Drive Units



    Power Handling

    Frequency Response

    Nominal Impedance

    Crossover Frequency

    Crossover Slope

    Dimensions (W/H/D)



    Download



    1 x 0.8" (20mm) Tweeter
    2 x 4" (10cm) Mid-Bass

    80 W RMS / 140 W max.

    70 - 20.000 Hz

    6 Ω

    3.000 Hz

    12 / 6 dB / Octave

    45 / 14 / 18 cm

    17.7 / 5.5 / 7 inch

    Manual

    • HD-W10BA

      Black Ash

    • HD-W10CH

      Cherry

    • HD-W10RW

      Rosewood



    HEIDELBERG, HD-W 10

    Active - Subwoofer



    Vented, active 10”/25cm subwoofer in a compact design. 150W RMS amplifier with onboard phase/volume and low-pass adjustors.



    Driver Units

    Power Handling

    Crossover Frequency

    Dimensions (W/H/D)



    Download



    1 x 10" (25 cm) Woofer

    150W RMS

    30 - 150 Hz

    38 / 43 / 45 cm

    15 / 19.6 / 17.7 inch

    Bedienungsanleitung
